Technical Specs:

Outputs

1x 1/8" stereo mini jack (LINE OUT)
1x 1/8" stereo mini jack (PHONE OUT)

MIC Weight

[XYH-6 X/Y]: 4.6 oz (130 g),
[MSH-6]: 3 oz (85 g)

MIC Dimensions (WxHxD)

[XYH-6 X/Y]: 3.1 x 2.4 x 1.8" (78.9 x 60.2 x 45.2 mm),
[MSH-6 MS]: 2.3 x 2.66 x 1.65" (58 x 67.6 x 42.1 mm)

MIC Maximum Input Sound Level

[XYH-6 X/Y]: 136 dB SPL,
[MSH-6 MS]: 120 dB SPL (unidirectional)
122 dB SPL (bi-directional)

MIC Polar Pattern

[XYH-6 X/Y]: Unidirectional,
[MSH-6 MS]: Unidirectional and bi-directional

Weight

9.9 oz (280 g)

Dimensions (WxHxD)

3 x 6 x 1.9" (77.8 x 152.8 x 47.8 mm)

Battery Life (approximate)

Over 20 hours (with alkaline battery, continuous recording)

Phantom Power

+12V /+24V /+48V, independent (INPUTS 1 to 4)
2.5V plug-in power, (XYH-6 MIC/LINE IN)

Recording Media

SD card: (16MB to 2GB), SDHC card: (4GB to 32GB), SDXC card: (64GB to 128GB)

Inputs

4 x XLR/TRS combo jacks; XLR: Pin 2 hot; TRS: Tip hot
1x 1/8" stereo mini jack (XYH-6 MIC/LINE IN)

Input Gain

-∞ to 55.5 dB (PAD OFF)
-∞ to 35.5 dB (PAD ON)

Recording Format

WAV, MP3

Bit Rate

48/56/64/80/96/112/128/160/192/224/256/320 kbps (MP3)

Bit Depth

16, 24 (WAV)

Sample Rate

44.1/48/96kHz (WAV), 44.1kHz (MP3)

Record Time

With 2 GB card:
03:08:00 (44.1 kHz / 16-bit WAV),
34:43:00 (128 kbps MP3)
